Diamondback Podium 6 Road Bike Ultegra 2012
$2,799.99
Great Deal at 18% markdown from $3400
Diamondback has raised the head tube height slightly this year to reduce the strain on the rider’s back and improve the overall fit. They have also incorporated a stiff BB30 and a longer wheelbase for a more efficient and comfortable ride. Shimano Ultegra drivetrain and brakes add to reliability over long rides, and the light carbon monocoque competition frame has internal cable routing and carbon drop outs. Cranks are FSA SLK-Light PF, and Easton outfits the seat post, handlebars and hubs. This bike is ready for the race.
- Frame:DBR AMMP Carbon Technology, Specific Modulous, Monocoque Competition Road Frame, internal cable routing, Carbon Drop outs, w/Taper headtube, Press-Fit 30 BB, Di2 Compatible
- Fork: DBR AMMP Carbon Competition Road Fork, Carbon Drop outs, w/Taper Carbon steerer tube, CFT Contiunuous Fiber Technology
- Headset: FSA No.42 , Sealed ACB for Taper Headtube
- Cranks: FSA SLK-LIGHT PF30 53,39t
- Bottom Bracket: PRESS FIT 30
- Front Derailleur: Shimano Ultegra, Braze on
- Rear Derailleur: Shimano Ultegra 10spd
- Shifter: Shimano Ultegra Dual Control 10spd Cogset (Casset/Freewheel): Shimano CS-6700 Ultegra 10spd (11-25t)
- Chain: Shimano CN-5700 10spd
- Front Hub: Easton Aero, 20h, V1, Cartridge Bearing
- Rear Hub: Easton Aero 24h Alloy Cassette V1 Cartridge Bearing
- Spokes: Black, Stainless Steel Bladed
- Rims: Easton Aero 31mm 20h frt / 24h rr
- Tires: Michelin Pro 3 700x23c
- Brakes: Shimano Ultegra dual pivot
- Brake Levers: Shimano Ultegra Dual Control 10spd
- Handlebar: Easton EC70 Aero, 31.8 Carbon
- Grips: DBR Race tape w/Gel
- Stem: Easton EA70, +/-6 degree , 31.8
- Seat: DBR Competition Road with NiCro Rails
- Seat Post: Easton EA70, 27.2mm
| Size | 50cm | 52cm | 54cm | 56cm | 58cm | 60cm |
| Seat Tube Length | 470.0mm | 490.0mm | 510.0mm | 530.0mm | 550.0mm | 570.0mm |
| Standover Height | 729.0mm | 755.0mm | 766.0mm | 786.0mm | 802.0mm | 828.0mm |
| Head Tube Length | 115.0mm | 135.0mm | 150.0mm | 165.0mm | 180.0mm | 205.0mm |
| Top Tube Length* | 515.0mm | 530.0mm | 545.0mm | 560.0mm | 575.0mm | 590.0mm |
| Head Angle | 72.0 | 72.3 | 72.8 | 73.0 | 73.0 | 73.0 |
| Seat Angle | 75.2 | 74.0 | 73.3 | 73.0 | 73.0 | 72.5 |
| Wheel Base | 967.0mm | 968.0mm | 975.0mm | 984.0mm | 998.0mm | 1009.0mm |
| Stem Length | 80.0mm | 90.0mm | 100.0mm | 100.0mm | 110.0mm | 120.0mm |
| Handlebar Width | 400.0mm | 400.0mm | 420.0mm | 420.0mm | 440.0mm | 440.0mm |
| Crank Length | 165.0mm | 170.0mm | 172.5mm | 172.5mm | 175.0mm | 175.0mm |
